IATF 16949 Certified SMT PCB Assembly with 0201 Component Placement and Full MES Traceability

Name: IATF 16949 Certified SMT PCB Assembly with 0201 Component Placement and Full MES Traceability
Brand: Guangdong Jiefu Technology Co., Ltd.
SKU: SMT PCB Assembly
Availability: InStock

Brand Name:	ODM OEM
Model Number:	SMT PCB Assembly
MOQ:	1PCS
Price:	Negotiable
Payment Terms:	Western Union,T/T
Supply Ability:	Double Sided: 12000 sq m / month Multilayers: 8000sq.m / month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, TS16949, UL, RoHS

Copper Thickness:

1oz,1/2OZ 1OZ 2OZ 3OZ,0.25 Oz -12 Oz,1 Oz,0.30z-30z

Base Material:

FR-4,CEM3,FR1,high TG FR4,Steel

Min. Line Spacing:

0.1mm,3mil,0.1mm4mil),0.003",3 Mil (0.075 Mm)

Board Thickness:

1.6mm,1.6mm-3.2mm,0.3mm-6mm,0.4~3mm,0.2mm-4.5mm

Min. Line Width:

3mil,0.1mm,0.1mm/4mi,0075MM=3MIL,0.075mm/0.075mm(3mil/3mil)

Min. Hole Size:

0.20mm,0.1mm,8 Mil/6 Mil,Machine Drilling 0.2mm; Laser Drilling 0.1mm,/

Surface Finishing:

HASL,ENIG,OSP,Lead Free HASL,HASL/OSP/ENIG

Product Name:

Pcb Board Assembly,Pcb Board Assembly Manufacturer With Electronic Components Mounting,AC110V 220V Infared Led Pcb Board,Printed Circuit Board,3528 Led 4-layer Number Multilayer 4 Layer Smt Pcb Assembly

Solder Mask:

Green,Green. Red. Blue. White. Black.Yellow,Blue,Customized,Yellow

Item:

ODM OEM LED PCBA,2 Layer Pcb,Keyboard Pcb Assembly,Custom Circuit Board

Type:

PCB Assembly,Customizable,Electronic Board,BMS

Name:

Factory SMT Pcb Assembly,SMT Electronic Component PCBA Circuit Board PCB Assembly,High Quality PCBA Boards Supplier,PCB Board Production

Service:

PCB/Components Sourcing/Soldering/Programming/Testing..,OEM Services Provided,PCB&PCBA,One-stop Turnkey Service,One Stop Turnkey Service

Application:

Consumer Electronics,PCBA Circuit Board,Communications/Auto Electric,rigid Fpc,PCB Assembly

Pcb Standard:

IPC-A-610 E,IPC-II Standard

Layers:

1-58layers,1-32,1-48

Packaging Details:

Vacuum Package+Carton Box

Supply Ability:

Double Sided: 12000 sq m / month Multilayers: 8000sq.m / month

Product Description

SMT PCB Assembly for Automotive Electronic Components

IATF 16949 certified SMT manufacturing for ADAS, infotainment, BMS, and sensor modules. From prototype to mass production, with full traceability.

🏆 IATF 16949 Certified

🔍 100% X-Ray on BGA

📋 Full Serial Traceability

Automotive SMT Challenges

Why Automotive SMT Is Harder Than You Think

Challenge	Description
❌ Hidden Defects = Field Failures	BGA and QFN solder joints look fine on the outside, but voids and cold joints cause failures after 6-12 months in the field. Warranty claims skyrocket.
❌ No Traceability = Recall Nightmare	When a quality issue surfaces, you can't pinpoint which batch, which machine, or which operator. Recalls become expensive guesswork.
❌ Consumer-Grade Lines = Automotive Risk	Standard SMT shops skip SPI, run cheaper components, and have no process control. They can't meet IATF requirements or PPAP documentation.

You need an SMT partner who understands automotive-grade standards. That's where we come in.

Our Solution

We combine IATF 16949 quality systems, triple inspection, and full MES traceability to deliver SMT assemblies that meet — and exceed — automotive reliability requirements.

Solution	Description
🛡️ Zero-Defect Inspection	3D SPI → 3D AOI → X-Ray triple inspection on every board. BGA void rate ≤ 5%, verified per IPC-A-610 Class 3 standards. No hidden surprises.
🔍 Full Traceability, Down to the Joint	Every board tracked by serial number through MES. Component lot, solder paste batch, reflow profile, inspection images — all linked and stored for 7+ years. PPAP-ready.
⚡ Prototype → Production, Seamlessly	Start with 5 samples on rapid prototyping lines. Scale to 50,000+ on dedicated standard lines. Same quality system, same traceability, every step.

Application Scenarios

Automotive Electronics We Build

Technical Specifications at a Glance

0.3mm

Min BGA Pitch

0201

Min Component Size

±0.035mm

Placement Accuracy

≥98%

First-Pass Yield

Precision Assembly

Minimum Component	0201 (0.6 × 0.3 mm)
Maximum Component	55 × 55 mm
Minimum BGA Pitch	0.3 mm
Minimum IC Pitch	0.35 mm
Placement Accuracy	±0.035 mm
Rejection Rate	≤0.3% (passives) / 0% (ICs)
Process Cpk	≥ 1.0 (3σ)

Board Range

Board Thickness	0.3 - 6.5 mm
Max Board Size	460 × 510 mm
PCB Layers	1 - 32 layers
SMT Lines	300+ (Yamaha YSM20 / YSM10)
Production Mode	Prototype → Low-volume → Mass

Quality Control

Quality That Stands Up to Automotive Standards

5-Stage Inspection Process

Inspection Stage	Inspection Items	Coverage
Incoming QC	Component authenticity, COC verification, lot registration	100% of materials
3D SPI	Solder paste volume, height, alignment, bridging	100% of boards
3D AOI	Missing parts, polarity, tombstone, offset, bridging, insufficient solder	100% of boards
X-Ray Inspection	BGA / QFN hidden joints, void rate measurement	All BGA/QFN components
Final QA	Visual inspection, dimensional check, functional test (on request)	AQL sampling or 100%

Key Quality Indicators

Indicator	Value	Standard
First-Pass Yield	≥ 98%	IPC-A-610 Class 3
BGA Void Rate	≤ 5%	IPC-7095
Solder Paste Tolerance	±15 µm	3D SPI verified

🏆 IATF 16949

📋 ISO 9001

🌿 ISO 14001

🔷 UL

🌍 RoHS

⚡ ESD S20.20

Production Process

How Your Boards Are Built

Step	Process	What Happens
1	📥 Order Review & DFM	Engineers review Gerber + BOM, flag any design issues
2	📦 Material Preparation	Components sourced, PCB fabricated, incoming quality check
3	🔬 Solder Paste Printing	Precision stencil printing with 3D SPI verification
4	🤖 Component Placement	Yamaha high-speed placement, 0201 to BGA 0.3mm
5	🔥 Reflow Soldering	Controlled temperature profile, 240±5°C (adjustable)
6	🔍 AOI + X-Ray Inspection	100% optical + X-Ray on BGA/QFN
7	🔧 Additional Processes	DIP / conformal coating / underfill / functional test
8	✅ Final QA & Packing	Final inspection, ESD packaging, shipping preparation

Delivery Schedule

⏱️ Prototype: 3-5 working days (standard components)
⚡ Rush Prototype: 24-48 hours available
📦 Mass Production: 10-20 working days (depends on volume)

Why Choose Us

Why Automotive Teams Partner With Jiefu

Advantage	Description
🏆 IATF 16949 Certified	Manufactured in IATF 16949 certified facilities with full automotive quality systems. PPAP, FMEA, and control plans available on request. You're not buying from a garage shop.
🔍 Full MES Traceability	Every board has a serial number. Every component lot, every reflow profile, every inspection image — stored and retrievable for 7+ years. Audit-ready, always.
⚡ Dual-Mode Production	Start with 5 prototypes on rapid lines. Scale to 100k+ on dedicated automotive lines. Same quality system, zero requalification headaches.
🏗️ One-Stop Turnkey	PCB fabrication → component sourcing → SMT assembly → DIP → coating → testing. One PO, one contact, zero coordination overhead. Focus on your design, we handle the rest.

Frequently Asked Questions

Q1: Are you IATF 16949 certified?

Our manufacturing partner holds IATF 16949 certification. All automotive assemblies are produced on certified lines with full quality documentation. PPAP packages available on request.

Q2: What's the minimum order quantity for automotive SMT?

We accept orders as small as 5 pieces for prototyping. For production runs, typical MOQ starts at 100 pieces. Talk to us about your project — we're flexible.

Q3: Do you support PPAP documentation?

Yes. We can provide PPAP Level 3 documentation including PFMEA, control plans, process flow diagrams, dimensional reports, and material certificates.

Q4: What component sizes can you place?

From 0201 (0.6×0.3mm) passives up to 55×55mm components. Fine-pitch BGA down to 0.3mm pitch.

Q5: How do you ensure component authenticity?

All components are sourced from authorized distributors or franchised suppliers. COC/COA documentation is available for every part. No gray market, no counterfeits.

Q6: Can you handle conformal coating and potting?

Yes. We offer selective conformal coating (acrylic, silicone, urethane), and epoxy potting for harsh-environment applications.

Q7: What testing services do you offer?

ICT (flying probe or bed-of-nails), FCT functional test, burn-in testing, X-Ray inspection, and visual inspection per IPC-A-610. Custom test fixtures can be developed.

Q8: How do you handle ESD protection?

Our entire production area is ESD-controlled per ANSI/ESD S20.20. All operators wear ESD smocks, wrist straps, and work on ESD-safe benches.

Got more questions? Ask our engineering team →

Ready to Start Your Automotive SMT Project?

Send us your Gerber files + BOM + assembly requirements. Our engineering team will review and send a detailed quote within 24 hours.

✅ No NDA? No problem — we sign NDAs on request.
✅ Not sure about your design? We offer free DFM feedback.
✅ Need samples first? We'll get you 5-10 prototypes in 3-5 days.
