3OZ Copper Thickness Multilayer PCB Board 1.55mm Finish Electronic Circuit Assembly

Product Description:

The Multilayer PCB Board is a highly sophisticated and versatile solution designed to meet the demanding requirements of modern electronic applications. This product excels in delivering exceptional performance through its advanced multilayer construction, which enhances signal integrity, reduces electromagnetic interference, and supports complex circuit designs. Whether you need a single, double, or multilayer PCB, this board is fully customizable to accommodate your unique project specifications.

One of the standout features of this multilayer printed circuit board is its superior finish achieved through precision CNC machining. The CNC finish ensures that each board is manufactured with high accuracy, providing clean edges, precise dimensions, and excellent surface quality. This level of craftsmanship is crucial for maintaining the reliability and durability of the circuit board in demanding environments.

The product offers extensive versatility in terms of copper thickness, ranging from 0.5 oz to 14 oz (18 to 490 micrometers). This wide range allows for customization based on current-carrying requirements, thermal management, and mechanical strength. The outer copper weight is adjustable between 0.5 oz and 5 oz, enabling designers to optimize the outer layers for enhanced conductivity and robust solderability. Such flexibility makes this multilayer rigid circuit board suitable for a broad spectrum of applications, from simple control circuits to high-power devices.

Our multilayer circuit board assembly services incorporate advanced manufacturing techniques to ensure each layer is perfectly aligned and bonded. This meticulous process results in a reliable and compact multilayer printed circuit board that supports high-density interconnections and complex routing. The multilayer circuit board assembly is carefully executed to minimize defects and improve overall electrical performance, making it ideal for use in telecommunications, aerospace, automotive, medical devices, and consumer electronics.

Customization is at the heart of this product offering. Whether you require a custom PCB tailored to specific dimensions, layer counts, or material properties, we provide comprehensive OEM services to bring your design concepts to life. Our OEM service ensures that every multilayer PCB board meets your exact technical and quality standards, enabling seamless integration into your product development cycle.

The multilayer rigid circuit board is engineered to withstand harsh operating conditions, including high temperatures, mechanical stress, and exposure to chemicals. This durability is essential for applications where reliability and longevity are critical. The combination of robust materials, precise CNC finishing, and stringent quality control processes guarantees a product that performs consistently over time.

In summary, our Multilayer PCB Board offers a powerful combination of advanced multilayer technology, customizable copper thickness, precise CNC finishing, and comprehensive OEM services. It is an ideal choice for engineers and designers seeking a reliable multilayer printed circuit board that can be tailored to complex and high-performance applications. With its superior multilayer circuit board assembly and robust construction, this product stands out as a leading solution in the world of printed circuit boards.

Features:

• Product Name: Multilayer PCB Board
• Type: Multilayer Rigid Circuit Board, Multilayer Printed Circuit Board, Multilayer Printed Wiring Board
• Solder Mask Color Options: Green, Blue, Yellow, Red, White, Black
• Finish Thickness: 1.55 ±10% mm
• Layer Number: 1 to 60 layers available
• PCB Fabrication Input: Gerber Files or BOM List
• Copper Thickness: 3 OZ

Technical Parameters:

Applications:

The Multilayer PCB Board, manufactured under the reputable brand Support OEM, is a highly versatile and reliable multilayer electronic circuit board designed to meet diverse industrial and commercial needs. Originating from Shenzhen, China, this multilayer printed wiring board is produced with strict adherence to international quality standards, holding certifications such as ISO9001, ISO14001, UL, and IATF16949. These certifications ensure that every multilayer electronic circuit board delivered is of superior quality, durability, and performance.

Suitable for both prototype development and mass production, the Multilayer PCB Board caters to various application occasions and scenarios across multiple industries. Its design flexibility allows it to be used in single, double, or multilayer configurations, making it ideal for complex electronic devices requiring high-density interconnections. The copper thickness ranges from 0.5oz to 14oz (18-490μm), with a standard copper thickness of 3oz, providing excellent electrical conductivity and heat dissipation properties necessary for demanding applications.

In the telecommunications industry, the multilayer printed wiring board is essential for manufacturing compact and high-performance routers, switches, and other network communication devices. It supports high-frequency signal transmission and ensures minimal interference, critical for maintaining reliable and fast communication. In the automotive sector, these multilayer electronic circuit boards are widely used in advanced driver-assistance systems (ADAS), infotainment units, and electric vehicle power management systems, where safety, precision, and durability are paramount.

Consumer electronics also benefit greatly from the Multilayer PCB Board. Smartphones, tablets, wearable devices, and home automation products rely on multilayer electronic circuit boards to achieve miniaturization without compromising functionality. The vacuum packaging and carton box packaging details ensure that each unit arrives in perfect condition, ready for immediate use or assembly. With a minimum order quantity of just one unit and negotiable pricing, the product is accessible for both small-scale projects and large manufacturing runs.

Furthermore, the product supports OEM services and accepts PCB fabrication based on Gerber files or BOM lists, providing custom PCB solutions tailored to specific customer requirements. The supply ability of 20,000 square meters per month guarantees timely delivery within 7-15 working days, supported by convenient payment terms including Western Union and T/T. Overall, the Multilayer PCB Board from Support OEM is an excellent choice for engineers and manufacturers seeking a reliable multilayer printed wiring board for a wide range of technological applications.
