Copper Thickness 0.5-14oz Multilayer PCB Board 1.55mm Finish Electronic Production

Product Description:

The Multilayer Printed Wiring Board is an advanced and highly reliable solution designed to meet the demanding requirements of modern electronic devices. This Multilayer Rigid Circuit Board offers superior electrical performance and mechanical strength, making it an ideal choice for complex circuitry applications across various industries, including telecommunications, automotive, medical, and consumer electronics.

One of the defining features of this Multilayer Printed Wiring Board is its flexible copper overall weight, ranging from 0.5 to 5 ounces. This range allows for customization based on the specific electrical current and thermal management needs of the application. The outer copper weight also spans from 0.5 to 5 ounces, providing additional flexibility to optimize the board’s conductivity and durability. Copper thickness is standardized at 3 ounces, ensuring consistent performance and reliable signal integrity across all layers of the board.

Our Multilayer Rigid Circuit Board is engineered with precision using CNC finishing technology, which guarantees high accuracy and exceptional surface quality. CNC finishing not only enhances the aesthetic appeal of the board but also improves the consistency and reliability of the final product by minimizing manufacturing defects. This level of precision is critical for ensuring seamless integration into complex electronic assemblies.

The soldermask color options for the Multilayer Printed Wiring Board are diverse, catering to both functional and aesthetic preferences. Available colors include green, red, blue, black, white, and yellow. These vibrant and durable solder masks provide excellent protection against oxidation and environmental contaminants, while also facilitating ease of inspection and soldering during assembly. The choice of soldermask color can also be used for differentiation in multi-board setups or to comply with specific industry standards.

Designed as a Multilayer Rigid Circuit Board, this product features multiple conductive layers separated by insulating substrates. This multilayer structure allows for more compact designs by accommodating complex routing and high-density interconnections within a smaller footprint. Such configurations are essential for modern electronics, where space-saving and performance optimization are critical.

The robust construction of the Multilayer Printed Wiring Board ensures high mechanical stability, excellent heat dissipation, and reliable electrical performance. Its ability to support high-frequency signals, reduce electromagnetic interference, and maintain signal integrity makes it a preferred choice for applications requiring advanced circuitry and reliable long-term operation.

In summary, this Multilayer Rigid Circuit Board combines customizable copper weights, precise CNC finishing, a variety of soldermask colors, and a standardized copper thickness of 3 ounces to deliver a versatile and high-performance solution. Whether you are designing consumer electronics, industrial equipment, or cutting-edge technology, this Multilayer Printed Wiring Board provides the quality, durability, and flexibility needed to bring your projects to life with confidence and efficiency.

Features:

• High-quality Multilayer Printed Circuit Board with a thickness of 1.6mm
• Surface finishing options: HASL, Lead Free HASL, OSP, and ENIG
• Available soldermask colors: Green, Red, Blue, Black, White, and Yellow
• Copper thickness ranges from 0.5 to 14 oz (18 to 490 μm) for versatile applications
• Copper overall weight between 0.5 and 5 oz, ensuring optimal conductivity
• Designed as a reliable Multilayer Electronic Circuit Board for complex electronic devices
• Ideal for use as a Multilayer Printed Circuit Board in various industrial and consumer electronics

Technical Parameters:

Applications:

The Multilayer PCB Board, produced by Support OEM in Shenzhen, China, is a highly versatile and reliable solution designed to meet the demanding needs of various industries. With certifications including ISO9001, ISO14001, UL, and IATF16949, this product ensures top-quality manufacturing standards and environmental responsibility. The Multilayer Printed Circuit Board is available with a layer number ranging from 1 to 60, accommodating complex electronic designs with ease. Its finish thickness is precisely controlled at 1.55 ±10% mm, and copper overall thickness varies from 0.5 to 5oz, providing excellent electrical performance and durability.

This Multilayer Rigid Circuit Board is ideal for applications requiring high-density wiring and compact designs. It is widely used in telecommunications, medical devices, automotive electronics, aerospace, and industrial control systems. The robust construction of the Multilayer Printed Wiring Board allows it to perform reliably under harsh conditions, making it suitable for critical applications such as avionics and defense-grade equipment. Its multilayer structure enables sophisticated signal routing, power distribution, and electromagnetic interference (EMI) control, which are essential in modern electronic devices.

Available in multiple soldermask colors, including green, blue, yellow, red, white, and black, the Multilayer PCB Board offers customization options to fit specific project requirements and enhance visual identification. The product is packaged securely using vacuum packaging combined with carton boxes to ensure safe delivery. With a supply ability of 20,000 square meters per month and a minimum order quantity of just one unit, it caters to both small-scale prototyping and large-scale manufacturing needs.

Support OEM offers flexible payment terms, including Western Union and T/T, and negotiable pricing to accommodate various budget constraints. Delivery time ranges between 7 and 15 working days, ensuring prompt fulfillment of orders. Whether you are developing cutting-edge consumer electronics, industrial machinery, or high-frequency communication devices, the Multilayer Printed Circuit Board, Multilayer Rigid Circuit Board, and Multilayer Printed Wiring Board from Support OEM provide an excellent balance of performance, quality, and customization for your projects.

Customization:

Our Multilayer PCB Board, proudly branded as Support OEM, offers exceptional customization services tailored to your needs. Manufactured in Shenzhen, China, our Multilayer Printed Circuit Board meets the highest standards with certifications including ISO9001, ISO14001, UL, and IATF16949, ensuring quality and reliability for your projects.

We support a minimum order quantity of just 1 unit, making it easy for you to prototype or scale your production. The price is negotiable to fit your budget, with packaging details featuring a vacuum package plus a carton box to ensure safe delivery. You can expect delivery within 7-15 working days, backed by a supply ability of 20,000 square meters per month.

Our Multilayer Printed Circuit Board boasts a thickness of copper ranging from 0.5 to 14oz (18-490um) and an overall copper thickness of 0.5-5oz, with a finish thickness of 1.55 ±10% mm. The soldermask color is blue, and we can manufacture boards with 1 to 60 layers to meet complex circuit requirements. Payment terms include Western Union and T/T for your convenience.

Choose our Multilayer Printed Circuit Board customization services to benefit from high-quality, flexible design options and reliable delivery, ensuring your electronic products perform optimally in any application.

Support and Services:

Our Multilayer PCB Boards are designed to meet the highest standards of quality and performance. For technical support, we provide comprehensive assistance, including design consultation, troubleshooting, and optimization tips to ensure your multilayer PCB functions flawlessly in your application.

Our experienced support team can guide you through stack-up configurations, material selection, impedance control, and signal integrity considerations specific to multilayer boards. We also offer design rule checks and panelization services to streamline your manufacturing process.

In addition to technical support, we provide value-added services such as prototype fabrication, quick-turn production, and rigorous quality testing, including electrical testing, X-ray inspection, and thermal analysis. These services help in reducing time to market and improving the reliability of your final product.

We are committed to delivering tailored solutions and ongoing support to help you achieve optimal performance from your multilayer PCB boards throughout their lifecycle.

Packing and Shipping:

Each multilayer PCB board is carefully packaged to ensure maximum protection during transit. The boards are first wrapped in anti-static bubble wrap to prevent any electrostatic discharge damage. They are then placed in sturdy, custom-sized cardboard boxes with additional cushioning materials to avoid any physical damage.

For bulk orders, the boards are stacked with protective sheets between each layer to prevent scratching and deformation. The boxes are securely sealed and clearly labeled with handling instructions such as "Fragile" and "Handle with Care."

We offer various shipping options, including standard, expedited, and overnight delivery to meet our customers’ needs. Tracking information is provided once the order is shipped, allowing customers to monitor their package until it arrives safely.

International shipments are carefully packaged to comply with customs requirements and ensure safe delivery worldwide. Our logistics partners are selected for their reliability and efficiency to guarantee the timely and secure shipping of your multilayer PCB boards.

FAQ:

Q1: What is the minimum order quantity for the Multilayer PCB Board?

A1: The minimum order quantity is 1 unit, making it convenient for both small and large-scale projects.

Q2: What certifications does the Multilayer PCB Board have?

A2: Our Multilayer PCB Board is certified with ISO9001, ISO14001, UL, and IATF16949 to ensure high quality and reliability.

Q3: Where is the Multilayer PCB Board manufactured?

A3: The Multilayer PCB Board is manufactured in Shenzhen, China, a major hub for advanced PCB production.

Q4: What are the packaging details for the Multilayer PCB Board?

A4: The product is securely packaged using a vacuum package combined with a carton box to ensure safe delivery.

Q5: What is the typical delivery time and payment terms for ordering the Multilayer PCB Board?

A5: Delivery time ranges from 7 to 15 working days, and we accept payment via Western Union and T/T.
