Yellow Soldermask Multilayer Pcb Assembly Gerber BOM Fabrication Electronic Production

Product Description:

The Multilayer PCB Board is a high-quality Multilayer Printed Circuit Board designed to meet the rigorous demands of modern electronic applications. Featuring a robust construction with a standard PCB thickness of 1.6mm and a finish thickness of 1.55 ±10%mm, this Multilayer Rigid Circuit Board offers exceptional durability and reliability. It is engineered to support complex circuit designs, making it an ideal choice for Multilayer Circuit Board Assembly in various industries including telecommunications, automotive, medical devices, and consumer electronics.

One of the standout features of this Multilayer Printed Circuit Board is its customizable Outer Cu Weight, which ranges from 0.5 to 5 oz. This flexibility allows designers to tailor the copper thickness according to the electrical and thermal requirements of their specific applications. Whether you need a lightweight board for fine-pitch components or a heavier copper layer for high-current circuits, this Multilayer Rigid Circuit Board can be adapted to suit those needs.

The surface finishing options available for this Multilayer PCB Board include HASL (Hot Air Solder Leveling), Lead-Free HASL, OSP (Organic Solderability Preservative), and ENIG (Electroless Nickel Immersion Gold). These finishing methods ensure excellent solderability, enhanced corrosion resistance, and long shelf life, providing superior performance during the Multilayer Circuit Board Assembly process. ENIG finish, in particular, is highly favored for its flat surface and excellent electrical conductivity, making it suitable for fine-pitch components and high-frequency applications.

In addition to technical specifications, this Multilayer Printed Circuit Board is available in a variety of soldermask colors including Green, Red, Blue, Black, White, and Yellow. This range of colors not only allows for aesthetic customization but also helps in distinguishing different layers or sections of the board during assembly and troubleshooting. The vibrant soldermask enhances the overall appearance and protects the copper circuitry from oxidation and short circuits.

With the combination of a precise finish thickness of 1.55 ±10%mm and a consistent PCB thickness of 1.6mm, the Multilayer PCB Board maintains excellent mechanical stability. This stability is critical for applications where the board may be subjected to mechanical stress or thermal cycling. The multilayer construction further increases the board's ability to handle complex routing and high-density component placement, which are essential for modern electronic devices.

Overall, the Multilayer PCB Board is a versatile and reliable solution for engineers and manufacturers seeking a high-performance Multilayer Printed Circuit Board. Its customizable copper weight, multiple surface finishing options, wide range of soldermask colors, and standard thickness specifications make it an excellent choice for a broad spectrum of applications. Whether for prototyping or large-scale production, this Multilayer Rigid Circuit Board supports efficient Multilayer Circuit Board Assembly, ensuring optimal electrical performance and durability.

Choosing this Multilayer PCB Board means investing in a product that combines advanced manufacturing techniques with customizable features to meet the evolving needs of the electronics industry. It is designed to provide consistent, high-quality results, enabling the creation of sophisticated electronic devices that perform reliably under demanding conditions. This makes it an indispensable component in the toolkit of modern electronics design and manufacturing.

Features:

• Product Name: Multilayer PCB Board
• Type: Multilayer Rigid Circuit Board
• Surface Finishing Options: HASL, Lead Free HASL, OSP, ENIG
• Soldermask Color Options: Green, Red, Blue, Black, White, Yellow
• Outer Copper Weight Range: 0.5-5 oz
• Copper Overall Thickness: 0.5-5 oz
• Layer Number: 1 to 60 layers
• Suitable for Multilayer Printed Circuit Board applications
• High-quality Multilayer Rigid Circuit Board for reliable performance

Technical Parameters:

Applications:

The Multilayer PCB Board, offered by Support OEM and manufactured in Shenzhen, China, is a highly versatile Multilayer Printed Circuit Board designed to meet the needs of various electronic applications. With certifications including ISO9001, ISO14001, UL, and IATF16949, this product guarantees high quality and reliability. Its multilayer structure allows for complex circuit designs, making it ideal for industries requiring compact and efficient electronic solutions.

This Multilayer Electronic Circuit Board is suitable for a wide range of application occasions and scenarios. It is extensively used in telecommunications equipment, where high-density and high-speed signal transmission are essential. The multilayer design supports advanced functionalities in mobile devices, routers, and communication base stations. Additionally, it finds applications in automotive electronics, supporting systems like advanced driver-assistance, infotainment, and engine control modules, benefiting from its robust construction and compliance with automotive standards.

In the industrial sector, this Multilayer Printed Wiring Board is perfect for control systems, automation equipment, and instrumentation, where durability and precision are crucial. It is also widely employed in medical devices, enabling compact and reliable circuit integration for diagnostic and monitoring equipment. Consumer electronics such as laptops, gaming consoles, and wearable devices also utilize these multilayer PCBs to optimize space and performance.

Customization is a key feature of this product, supporting single, double, and multilayer PCB configurations with soldermask colors including green, red, blue, black, white, and yellow. Surface finishing options like HASL, lead-free HASL, OSP, and ENIG provide flexibility based on application requirements. The outer copper weight ranges from 0.5 to 5 oz, allowing for tailored electrical performance. Packaging involves vacuum packaging combined with carton boxes to ensure safe delivery within 7-15 working days. With a supply ability of 20,000 square meters per month and a minimum order quantity of just one unit, it is suitable for both small-scale prototyping and large production runs.

Payment terms such as Western Union and T/T provide convenience for global customers, and the price remains negotiable to meet various budgetary needs. Whether for prototype development or mass production, the Multilayer PCB Board by Support OEM stands out as a reliable and adaptable choice for numerous electronic applications requiring high-performance multilayer printed circuit boards.

Customization:

Our Multilayer PCB Board, proudly branded as Support OEM, is a high-quality Multilayer Rigid Circuit Board designed and manufactured in Shenzhen, China. With certifications including ISO9001, ISO14001, UL, and IATF16949, we ensure top-notch quality and reliability for your electronic needs.

We specialize in custom Multilayer Electronic Circuit Board fabrication, supporting orders starting from a minimum quantity of just 1 unit. Our pricing is negotiable to best suit your project requirements.

The Multilayer Printed Wiring Board features a finish thickness of 1.55 ±10%mm and comes with a blue soldermask color. Surface finishing options include HASL, Lead-Free HASL, OSP, and ENIG, with precise CNC finishing to guarantee excellent performance and durability.

Packaging is handled with care using vacuum packaging combined with sturdy carton boxes to ensure safe delivery. Our supply ability reaches up to 20,000 square meters per month, with delivery times ranging from 7 to 15 working days.

We accept payment via Western Union and T/T, providing flexible terms to accommodate your convenience. For fabrication, we work directly from Gerber files or BOM lists, allowing for seamless customization and production of your multilayer PCB boards.

Support and Services:

Our Multilayer PCB Board product is designed to meet the highest standards of quality and reliability for complex electronic applications. We offer comprehensive technical support to assist you throughout the entire lifecycle of the product, from design to manufacturing and testing.

Our experienced technical team is available to provide guidance on multilayer PCB stack-up configurations, material selection, impedance control, and signal integrity to ensure optimal performance of your circuit designs. We also offer design rule checks and layout optimization services to help minimize manufacturing defects and enhance yield.

In addition to design support, we provide detailed documentation including fabrication drawings, assembly instructions, and testing protocols. Our quality assurance services include electrical testing, X-ray inspection, and automated optical inspection (AOI) to guarantee the integrity of every multilayer PCB delivered.

For any technical issues or troubleshooting needs, our support team is ready to assist with quick response times and effective solutions. We also offer repair and rework services for multilayer PCBs to extend the life of your assemblies and reduce downtime.

We are committed to continuous improvement and innovation, offering the latest advancements in multilayer PCB technology and materials to help you stay ahead in the competitive electronics market.

Packing and Shipping:

Our Multilayer PCB Boards are carefully packaged to ensure maximum protection during transit. Each board is individually wrapped in anti-static bubble wrap to prevent electrostatic discharge and physical damage.

The wrapped PCBs are then placed in sturdy, custom-sized cardboard boxes with additional cushioning materials to absorb shocks and vibrations.

For bulk orders, boards are stacked with protective sheets between each layer to avoid scratches and deformation.

All packages are clearly labeled with handling instructions and product details to facilitate safe and efficient shipping.

We partner with reliable and experienced courier services to guarantee timely delivery and to track your shipment until it reaches your doorstep.

Special packaging options are available upon request for sensitive or high-value orders.

FAQ:

Q1: What is the minimum order quantity for the Multilayer PCB Board?

A1: The minimum order quantity for the Multilayer PCB Board is 1 unit.

Q2: Where is the Multilayer PCB Board manufactured?

A2: The Multilayer PCB Board is manufactured in Shenzhen, China.

Q3: What certifications does the Multilayer PCB Board have?

A3: The Multilayer PCB Board is certified with ISO9001, ISO14001, UL, and IATF16949.

Q4: What are the payment terms available for purchasing the Multilayer PCB Board?

A4: Payment can be made via Western Union or T/T (Telegraphic Transfer).

Q5: How long does it take to deliver the Multilayer PCB Board after placing an order?

A5: The delivery time for the Multilayer PCB Board is typically between 7 to 15 working days.
