High-Reliability Multilayer HDI PCBA Board Assembly for Industrial IoT Systems

Name: High-Reliability Multilayer HDI PCBA Board Assembly for Industrial IoT Systems
Brand: Guangdong Jiefu Technology Co., Ltd.
SKU: PCBA Board Assembly
Availability: InStock

Brand Name:	ODM OEM
Model Number:	PCBA Board Assembly
MOQ:	1PCS
Price:	Negotiable
Payment Terms:	T/T,Western Union
Supply Ability:	Double Sided: 12000 sq m / month Multilayers: 8000sq.m / month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, TS16949, UL, RoHS

Solder Mask Color:

Green, Red, Blue, Black, White, Yellow

Productname:

PCBA Board Assembly

Minimumholesize:

0.2mm

Standard Testing:

IPC Class 2

Soldering Method:

Reflow Soldering And Wave Soldering

Copper Thickness:

1/3oz-6oz

Welding Mode:

Smt Patch Welding + DIP Plug-in Welding

Pcb Size:

160*132mm

Assemblytolerance:

±0.1mm

Boardthickness:

1.6mm

Componenttype:

SMT And Through-Hole

Components Type:

Point:

272

Testing:

100% E-test

Packaging Details:

Vacuum Package+Carton Box

Supply Ability:

Double Sided: 12000 sq m / month Multilayers: 8000sq.m / month

Product Description

PCBA Board Assembly for Industrial IoT | Multilayer HDI & High-Reliability Solutions

High-reliability PCBA Board Assembly for industrial control, smart manufacturing, and IoT systems — from prototype to mass production.

2-64 Layers | 0.3mm Min BGA Pitch | -40°C to +85°C Operating Range | ≥98% First-Pass Yield

Technical Specifications

PCB Manufacturing	SMT Assembly
1-64 Layers	Min Component: 0201
HDI 1/2/3	Min BGA Pitch: 0.3mm
A-grade FR4 / Rogers / PTFE	Placement Accuracy: ±0.035mm
Max Copper: 6oz	300+ Production Lines
Impedance Control: ±10%	SPI + AOI + X-Ray
Min Line/Space: 3mil	Yield: ≥98%

Application Scenarios

PLC / DCS Controllers
Industrial IoT Gateways
Motor Drives & Inverters
Sensor Modules
Power Monitoring Systems
Robotics Control Boards
Building Automation
Agricultural IoT

Quality Certification

Service Process

DFM Review → PCB Fabrication → Component Sourcing → SMT + DIP Assembly → Testing & Burn-in → Conformal Coating → Global Shipping

Frequently Asked Questions

What's your MOQ for PCB & PCBA?

We have low MOQs:

PCB: 1 piece minimum
PCBA: 1 unit minimum
We support both prototype and mass production orders

How fast can you deliver?

Typical lead times:

PCB prototype: 3-5 days
Standard PCB: 5-7 days
PCBA assembly: 7-12 days (including parts sourcing)
Expedited service available for urgent orders

What files do I need to send?

Please provide:

Gerber files (274X preferred)
BOM (Bill of Materials)
Centroid/XY data (for SMT)
Assembly drawings (optional but helpful)

Our team can help you check the files before production.

Do you source components?

Yes, we offer one-stop component sourcing:

We source original and equivalent parts
We also accept customer-supplied components
All parts go through strict incoming quality checks

What certifications do you have?

We follow strict quality standards:

ISO 9001 certified
UL-approved PCB manufacturing
IATF 16949 compliant for automotive projects
We do AOI, X-ray, and functional testing on every order

What types of PCB/PCBA can you make?

We handle a wide range of projects:

Rigid, flexible, rigid-flex, HDI, and multilayer PCB
SMT, THT, and mixed assembly
HASL, ENIG, OSP, and other surface finishes

Tell us your specs, and we'll quote accordingly.

How do I get a quotation?

It's easy:

Send us your Gerber, BOM and special requirements
We review and reply within 24 hours
You get a clear quote with price, lead time and terms
No hidden fees

What payment methods do you accept?

We accept:

T/T (wire transfer)
PayPal
Western Union
Flexible terms available for large orders

How do you ship the orders?

We ship worldwide via reliable carriers:

DHL, UPS, FedEx for fast delivery
Air/sea freight for bulk orders

Full tracking and customs support available.

What after-sales support do you provide?

We stand behind our work:

100% inspection before shipping
Free rework/replacement for quality issues
Technical support from our engineers anytime
