AOI Test Rigid Flexible PCB Polyimide Base Material For Medical Automotive

Product Description:

Rigid flexible PCB, also known as rigid-flex boards, is a revolutionary product that combines the benefits of both rigid and flexible circuit boards. It offers the flexibility of a flexible circuit and the stability of a rigid board, making it the perfect solution for various applications in different industries.

Rigid flexible PCBs are available in two colors: green and blue. These colors are commonly used in the electronics industry and can be easily customized according to the customer's preference.

Rigid flexible PCBs are widely used in various industries such as automotive, industrial, medical, data communication, and consumer electronics. Its versatility and flexibility make it the ideal choice for different applications.

Our company offers a one-stop service for designing and manufacturing rigid flexible PCBs. We have a team of experienced engineers who can provide customized solutions that meet the specific requirements of our customers. From design to production, we ensure that our customers receive the highest quality and most cost-effective products.

In addition to our one-stop service, we also provide OEM (Original Equipment Manufacturer) and DFM (Design for Manufacturability) services. With our advanced technology and expertise, we can help our customers develop their own unique rigid flexible PCBs and ensure that they are designed for efficient and cost-effective production.

Our rigid flexible PCBs undergo rigorous testing to ensure their quality and reliability. We use advanced X-ray, AOI (Automated Optical Inspection), and functional testing methods to detect any defects or issues and ensure that our products meet the highest industry standards.

Our rigid flexible PCBs are designed with precision and accuracy, and we can achieve a minimum drilling size of 0.0078” (0.2mm). This allows for more compact and efficient designs, making our products suitable for even the most demanding and complex applications.

In conclusion, our rigid flexible PCBs offer a combination of flexibility, stability, and high-quality performance, making them the perfect solution for a wide range of industries and applications. Contact us today to learn more about how our products can benefit your business.

Features:

• Product Name: Rigid flexible PCB
• Polyimide Base Material: Polyimide Flex
• Cu Weight: 0.5-4 0z
• Pcba Test: X-ray,AOI Test,Functional Test
• Service: One-stop Service / OEM,DFM
• Layer Count: 1-36 Layers
• Rigid Flex Hybrid PCB
• Flexible-rigid printed circuit board
• Rigid Flex Hybrid PCB manufacturer
• Polyimide circuit board
• PCB fabrication
• PCB assembly

Technical Parameters:

Applications:

Rigid-Flexible PCB, also known as Flex-Rigid Circuit Boards, is a type of printed circuit board that combines the features of both rigid and flexible printed circuit boards. It is widely used in various electronic products due to its unique characteristics.

Color: Rigid-Flexible PCBs are available in a variety of colors, including green and blue. These colors can be customized according to the specific requirements of the product to provide a stylish and aesthetic appearance.

Minimum Bend Radius: One of the most important features of Rigid-Flexible PCB is its ability to bend without damaging the circuit. The minimum bend radius of 0.5mm allows the board to be bent in different directions, making it suitable for use in various products with different shapes and sizes.

Solder Mask: The solder mask on a Rigid-Flexible PCB is used to protect the copper traces from oxidation and corrosion. It also provides insulation between the conductive traces, ensuring the stability and durability of the circuit. The solder mask is available in various colors such as yellow, blue, black, and white, providing options for different product designs.

Drilling Size: Rigid-Flexible PCBs have a minimum drilling size of 0.0078”(0.2mm), which allows for the placement of smaller components and more complex circuit designs. This feature makes it suitable for use in high-density circuit applications.

Certificates: Rigid-Flexible PCBs are manufactured in compliance with international standards such as ISO9001, ISO14001, IATF16949, and UL. These certificates ensure that the product meets the highest quality standards and is safe to use in various electronic products.

Application Scenarios: Rigid-Flexible PCBs are widely used in various electronic products, including smartphones, tablets, laptops, wearable devices, medical equipment, and automotive electronics. Its flexibility, durability, and high-density circuit design make it suitable for use in these products.

Conclusion: Rigid-Flexible PCBs, also known as Flexible-rigid printed circuit boards or Flexible Printed Circuit Boards, are a versatile and essential component in the electronics industry. Its unique features make it suitable for use in various applications, providing a reliable and efficient solution for complex circuit designs.

Customization:

Rigid Flexible PCB, also known as Bending Circuit Boards or Flexible-Rigid Printed Circuit Board, is a unique type of PCB that combines the advantages of both rigid and flexible circuits. It offers great flexibility and reliability, making it suitable for various applications in industries such as aerospace, medical, and automotive.

At our company, we offer one-stop customization services for Rigid Flexible PCBs. With our expertise and advanced technology, we can provide you with high-quality, customized PCB solutions to meet your specific requirements.

Our Rigid Flexible PCBs can be drilled with a minimum size of 0.0078” (0.2mm), ensuring precise and accurate drilling for your designs.

We offer a variety of color options for our Rigid Flexible PCBs, including green and blue. These colors are not only aesthetically pleasing but also help with identification and organization during the assembly process.

Our Rigid Flexible PCBs are made with high-quality Polyimide Flex material, which offers excellent thermal stability, chemical resistance, and flexibility. This material is ideal for applications that require high-temperature resistance and flexibility.

We provide a range of solder mask options for our Rigid Flexible PCBs, including yellow, blue, black, and white. These masks not only protect the PCB from environmental factors but also help with soldering and testing processes.

With our one-stop service, we can handle the entire process of Rigid Flexible PCB production, from design and prototyping to manufacturing and assembly. This streamlined process saves you time and resources, making it a cost-effective solution for your PCB needs.

We offer OEM (Original Equipment Manufacturing) services for Rigid Flexible PCBs, allowing you to customize the product with your own brand. Additionally, our DFM (Design for Manufacturability) service ensures that your design is optimized for efficient and cost-effective production.

Choose our Rigid Flexible PCB customization service for reliable and high-quality solutions tailored to your specific needs. Contact us today to learn more.

Packing and Shipping:

At Rigid-Flexible PCB, we understand the importance of safe and secure packaging for our products. That's why we use the highest quality materials and techniques to ensure that your Rigid-Flexible PCBs arrive at their destination in perfect condition.

Our Rigid-Flexible PCBs are first wrapped in anti-static bubble wrap to protect them from any potential damage during shipping. They are then placed in strong, corrugated cardboard boxes that are specifically designed for electronic components. These boxes are sealed with heavy-duty tape to ensure that they stay closed during transportation.

We also offer custom packaging options for our customers who have specific requirements. Our team is happy to work with you to create a packaging solution that meets your needs.

We offer various shipping options to meet your timeline and budget. Our standard shipping method is through reputable courier services such as FedEx or DHL. We also offer express shipping for urgent orders.

Before shipping, our quality control team checks each Rigid-Flexible PCB for any defects or damage to ensure that only the highest quality products are delivered to our customers.

For international orders, we take extra care in packaging and labeling to comply with customs regulations and to ensure a smooth delivery process.

Once your order has been shipped, we will provide you with a tracking number so you can monitor the progress of your shipment and know exactly when to expect its arrival.

At Rigid-Flexible PCB, we are committed to providing our customers with the best products and services. Our packaging and shipping processes are an integral part of that commitment, and we strive to continuously improve and exceed our customers' expectations.

FAQ:

• Rigid flexible PCB allows for more compact and lightweight designs, making it suitable for devices with limited space.
• It eliminates the need for multiple interconnects and connectors, reducing assembly time and costs.
• Rigid flexible PCB has higher reliability and better shock and vibration resistance compared to traditional rigid PCB.
• It offers more design flexibility, allowing for 3D shapes and contours to be incorporated into the PCB.
• Rigid flexible PCB can be bent and folded without compromising functionality, making it suitable for flexible and wearable electronic devices.

• Proper bending and folding radius must be considered to avoid damaging the flexible materials.
• The size and thickness of the rigid and flexible areas must be balanced to ensure structural integrity and functionality.
• Compensation for different thermal expansion coefficients between rigid and flexible materials must be taken into account.
• Electromagnetic interference (EMI) shielding may need to be incorporated in the design for high-frequency applications.
• The number and location of plated through-holes must be carefully planned to avoid compromising the flexibility of the PCB.
