Industrial Rigid Flexible PCB in Blue Color with and Cu Weight Range of 0.5-4 0z

Industrial Rigid Flexible PCB in Blue Color with and Cu Weight Range of 0.5-4 0z

Detail Information
Polyimide Base Material:
Polyimide Flex
Service:
One-stop Service / OEM,DFM
Layers:
1-36layers
Maximum Panel Size:
600mm X 1200mm
Drilling Size:
Min 0.0078”(0.2mm)
Function Test:
100% Functional Test
Certificates:
ISO9001, ISO14001, IATF16949, UL
Cu Weight:
0.5-4 0z
Product Description

Product Description:

Our flexible-rigid printed circuit board is available in a variety of sizes and shapes to meet your unique requirements. Whether you need a square, circle, or irregular-shaped PCB with jigs, we have the solution you need.

Our flex-rigid PCB features 2-8 layers, making it the perfect choice for a wide range of applications. With a maximum panel size of 600mm x 1200mm, you can be sure that our PCB will meet your needs, no matter what your project requires.

Our flexible-rigid printed circuit board is designed with a minimum bend radius of just 0.5mm, making it ideal for applications where flexibility is a must. With a polyimide base material, our flex-rigid PCB is built to last, providing reliable performance even in demanding environments.

So if you're looking for a flexible printed circuit board that you can rely on, look no further than our flex-rigid PCB. With a wide range of sizes and shapes to choose from, and built to withstand even the most demanding applications, our PCB is the perfect choice for your next project.


Features:

  • Product Name: Rigid Flexible PCB
  • Maximum Panel Size: 600mm X 1200mm
  • Function Test: 100% Functional Test
  • Cu Weight: 0.5-4 0z
  • Minimum Bend Radius: 0.5mm
  • Layer Count: 2-8 Layers
  • Rigid-flex boards
  • Flex-rigid printed circuit boards
  • Flexible-rigid printed circuit board

Technical Parameters:

Polyimide Base Material Polyimide Flex
Certificates ISO9001, ISO14001, IATF16949, UL
Service One-stop Service / OEM,DFM
Application Segment Auto, Industrial, Medical, DataCom、Comsumer
Minimum Bend Radius 0.5mm
Maximum Panel Size 600mm X 1200mm
Drilling Size Min 0.0078”(0.2mm)
Solder Mask Yellow, Blue, Black, White...
Color Green,blue
Layer Count 2-8 Layers

Rigid-Flexible Printed Circuit Boards, Flexible Printed Circuit Board, Rigid-Flex Circuitry


Applications:

The Flex-Rigid PCB is widely used in the automotive industry where its flexibility and durability make it an ideal solution for the harsh environments. The product is used in the manufacturing of airbag control units, engine control units, and other electronic components in vehicles that require high reliability and resistance to vibration and shock.

In the industrial sector, Flex-Rigid Circuit Boards are used in high-performance and precision instruments such as automation equipment, sensors, and control systems. The product's ability to withstand high temperatures and vibrations makes it an excellent choice for harsh industrial environments.

The medical sector also uses Flex-Rigid PCBs in various applications such as medical devices, diagnostic equipment, and implantable devices. The product's flexibility, durability, and biocompatibility make it an ideal choice for medical applications.

DataCom and consumer electronics industries also use Flex-Rigid PCBs in various applications such as smartphones, tablets, and laptops. The product's ability to reduce the size and weight of electronic devices makes it an excellent choice for these applications.

The Flex-Rigid PCB product has a layer count of 2-8 layers, and its minimum bend radius is 0.5mm, making it an ideal solution for applications where space is limited. The product also undergoes 100% functional testing to ensure its reliability and performance.
