Electronic Flexible PCB Board Thickness 0.15mm 0.2mm Customizable

Product Description:

The Flexible PCB Board is an advanced and versatile solution designed to meet the evolving needs of modern electronic applications. As a premier Flexible Electronic Circuit Board, it offers exceptional adaptability, durability, and performance, making it ideal for a wide range of industries including consumer electronics, automotive, medical devices, and industrial equipment. This product is engineered to provide outstanding electrical connectivity while accommodating complex design requirements and spatial constraints.

One of the defining features of this Flexible Circuitry Board System is its impressive minimum trace width of 0.05mm. This fine trace capability allows for high-density circuit designs, enabling more compact and intricate layouts without compromising signal integrity or reliability. The precision manufacturing process ensures that each trace is accurately produced, which is crucial for applications requiring detailed electronic interconnections and miniaturization.

The Flexible PCB Board is available with a variety of solder mask colors to suit different aesthetic and functional needs. Customers can choose from Green, Blue, Red, Black, or White solder masks, allowing for customization and color coding in multi-layered systems or complex assemblies. This variety not only enhances the visual appeal but also aids in identifying different circuit sections during assembly and maintenance.

Customization is a cornerstone of this product, as the size of the Flexible Electronic Circuit Board is made according to customer requests. This flexibility in sizing ensures that the board can be perfectly tailored to fit specific design constraints and application requirements. Whether the project demands a small, compact board or a larger, more expansive layout, the manufacturing process can accommodate these needs with precision and efficiency.

In terms of durability and electrical performance, the Flexible PCB Board features a copper thickness of 3OZ. This substantial copper weight provides excellent current-carrying capacity and enhanced thermal management, which is vital for high-power applications or environments with elevated temperatures. The thicker copper layer also contributes to the mechanical strength of the circuitry, ensuring long-lasting reliability even under repeated bending or flexing.

Protection against environmental factors is another significant advantage of this Flexible Circuitry Board System. It comes with various IP grade options including IP65, IP67, IP20, and IP68, offering different levels of ingress protection against dust, moisture, and water. This range of IP ratings makes the Flexible Electronic Circuit Board suitable for use in harsh conditions, whether it’s exposure to water splashes, dust-laden environments, or even temporary submersion. Such versatility broadens the scope of applications and guarantees dependable operation in diverse settings.

Overall, this Flexible PCB Board stands out as a highly adaptable and robust solution for modern electronic designs. Its fine minimum trace width, customizable sizes, multiple solder mask color options, thick copper layers, and comprehensive IP protection make it a preferred choice for manufacturers seeking to integrate flexible electronics into their products. Whether used in wearable technology, automotive sensors, or complex industrial machinery, this Flexible Electronic Circuit Board delivers exceptional performance, reliability, and design freedom.

Choosing this Flexible Circuitry Board System means investing in cutting-edge technology that supports innovation and efficiency. It empowers engineers and designers to push the boundaries of traditional electronics by enabling flexible, lightweight, and compact circuit designs without sacrificing durability or functionality. With its superior specifications and customizable options, this product is an essential component for any project that demands high-quality flexible electronic solutions.

Features:

• Product Name: Flexible PCB Board
• Soldermask Color Options: Green, Blue, Red, Black, White
• Solder Mask: Yellow Green
• Size: According To Customer Request
• Maximum Panel Size: 32＂×20＂ (800mm×508mm)
• PCB Type: Customizable
• Supports Flexible Multi-layer Circuit Board design
• Ideal for Flexible Circuitry Board System applications
• High-quality Flexible Printed Circuit Board manufacturing

Technical Parameters:

Applications:

The Flexible Printed Circuit Board (FPCB) is an essential component in modern electronic design, offering unparalleled versatility and adaptability. With its customizable nature and a thickness range from 0.1mm to 0.3mm, this product can be tailored to meet a wide array of application requirements. The yellow-green solder mask not only provides excellent protection against oxidation and environmental damage but also ensures clear visibility for inspection and maintenance, making it ideal for intricate electronic assemblies.

One of the primary application occasions for the Flexible Electronic Circuit Board is in wearable technology. Due to its thin and flexible nature, it comfortably conforms to curved surfaces and dynamic movements, making it perfect for smartwatches, fitness trackers, and health monitoring devices. The 3OZ copper thickness ensures reliable electrical conductivity and durability, which is crucial for devices used in active and demanding environments.

In the automotive industry, the Flexible Multi-layer Circuit Board plays a vital role in advanced driver-assistance systems (ADAS), infotainment systems, and sensor modules. Its customizable design allows engineers to integrate complex circuitry within limited space constraints, contributing to lighter and more efficient vehicle electronics. The flexibility and robustness provided by this PCB type help withstand vibrations and temperature variations typically encountered in automotive settings.

Consumer electronics also benefit significantly from flexible PCBs. Smartphones, tablets, and laptops utilize flexible electronic circuit boards to connect various components within tight spaces without compromising performance. The multi-layer capability enables high-density interconnections while maintaining a slim profile, which is essential for modern compact devices.

Furthermore, medical devices such as portable diagnostic equipment and implantable devices employ Flexible Printed Circuit Boards due to their biocompatibility and ability to be customized for specific functional needs. The yellow-green solder mask ensures the circuit’s longevity and resistance to harsh sterilization processes.

Industrial automation and robotics industries also leverage the advantages of flexible multi-layer circuit boards. Their ability to endure repetitive motion and mechanical stress makes them suitable for robotic arms, sensors, and control systems that require reliable and continuous operation.

In summary, the Flexible Printed Circuit Board with its yellow-green solder mask, customizable design, thickness ranging from 0.1mm to 0.3mm, and 3OZ copper thickness is highly adaptable across various application scenarios. From wearable technology, automotive electronics, consumer gadgets, medical devices, to industrial automation, this flexible electronic circuit board meets diverse industry demands by providing durability, flexibility, and high performance.

Customization:

Our Flexible PCB Board product offers comprehensive customization services to meet your specific needs. Samples are available to ensure the quality and compatibility of your design before full production. We manufacture Flexible Circuit Board Modules tailored to your exact size requirements, providing flexibility in dimensions to suit various applications.

We specialize in producing Flexible Multi-layer Circuit Boards with up to 8 layers, enabling complex and compact circuit designs. The thickness of our flexible PCBs can be customized to 0.15mm or 0.2mm, with a tolerance of ±10%, ensuring optimal performance and durability for your project.

Our advanced manufacturing capabilities allow for minimum trace widths as fine as 0.05mm, supporting high-density circuit layouts and precise electrical connections. Whether you need a single-layer or a sophisticated Flexible Multi-layer Circuit Board, our customization services are designed to deliver high-quality, reliable flexible PCBs tailored to your specifications.

Packing and Shipping:

Our Flexible PCB Boards are carefully packaged to ensure maximum protection during transit. Each board is individually wrapped in anti-static material to prevent electrostatic discharge damage. The wrapped boards are then placed in custom-designed, sturdy cardboard boxes with foam inserts to minimize movement and absorb shocks.

For bulk orders, multiple boxes are securely packed into a larger shipping carton with additional cushioning materials to safeguard against impact and vibration. All packages are clearly labeled with handling instructions and product information to facilitate safe and efficient delivery.

We offer various shipping options including standard, expedited, and freight services to meet your timeline requirements. Tracking information is provided promptly after dispatch, allowing you to monitor your shipment until it arrives at your specified destination.

Our packaging and shipping process is designed to ensure that your Flexible PCB Boards arrive in perfect condition, ready for immediate use in your applications.

FAQ:

Q1: What materials are used in the Flexible PCB Board?

A1: Our Flexible PCB Boards are made from high-quality polyimide film and copper foil, ensuring excellent flexibility, durability, and thermal resistance.

Q2: What are the typical applications for Flexible PCB Boards?

A2: Flexible PCB Boards are widely used in wearable devices, medical equipment, automotive electronics, aerospace, and consumer electronics due to their ability to fit into compact and irregular spaces.

Q3: What is the maximum number of layers available for your Flexible PCB Boards?

A3: We offer Flexible PCB Boards with up to 12 layers, allowing for complex circuit designs while maintaining flexibility and reliability.

Q4: Can Flexible PCB Boards withstand high temperatures?

A4: Yes, our Flexible PCB Boards are designed to withstand high operating temperatures, typically up to 200°C, making them suitable for demanding environments.

Q5: What is the minimum bend radius for your Flexible PCB Boards?

A5: The minimum bend radius depends on the thickness and design, but generally, our Flexible PCB Boards can be bent to as low as 5mm without compromising performance.
