Layer Count PCB With 0.1mm Solder Mask Clearance For Reliability And RoHS Compliance

Product Description:

Our High Layer PCBs are made with top-quality FR-4 material, ensuring high-performance and durability. With a copper thickness ranging from 1/3 oz to 2 oz, these boards can handle high currents and offer excellent thermal conductivity.

Our High Layer PCBs are RoHS compliant, meaning they are free from hazardous materials and environmentally friendly. This ensures that our PCBs meet all the necessary standards and regulations, making them safe for use in any application.

With a minimum hole size of 0.2mm and a minimum solder mask clearance of 0.1mm, our High Layer PCBs offer greater design flexibility and accuracy. These features make it possible to create complex designs with a high degree of precision and reliability, allowing you to achieve your desired results with ease.

Our High Layer PCBs are suitable for a wide range of applications, including aerospace, medical, telecommunications, and industrial electronics. With their high-performance capabilities and reliable design, they are the perfect solution for any project that requires a Multi Layer PCB.

Overall, our High Layer PCBs are designed to meet the demands of high-density interconnect boards, offering greater flexibility and functionality in your electronic applications. With top-quality FR-4 material, RoHS compliance, and a range of impressive features, our High Layer PCBs are the perfect solution for any project that requires a reliable and efficient Multi Layer PCB.

Features:

• Product Name: High Layer PCB
• Type: High Density Interconnect Board, High Layer Circuit Board
• Min. Solder Mask Clearance: 0.1mm
• Board Thickness: 0.2mm To 6.0mm
• Min. Hole Size: 0.2mm
• Rohs Compliant: Yes
• Solder Mask Color: Green, Blue, Black, Red, Yellow, White

Technical Parameters:

Applications:

The High Layer PCB product with Surface Finish options including HASL, ENIG, OSP, Immersion Silver, and Immersion Tin are well-suited for applications in the automotive and aerospace industries, where high performance and reliability are essential. These PCBs can be used in engine control units, airbag control modules, and other safety-critical systems, where the reliability of the circuit board is essential for the safety of the vehicle or aircraft.

Another application for High Layer PCBs is in the medical industry, where these boards can be used in equipment such as MRI machines, ultrasound equipment, and patient monitoring systems. With a board thickness ranging from 0.2mm to 6.0mm, these PCBs can be customized to meet the requirements of specific medical devices.

The High Layer PCB product is also well-suited for use in telecommunications equipment, such as routers, switches, and servers. With the ability to handle high-speed data transmission, these PCBs can help improve the performance and reliability of telecommunications equipment.

Rohs compliant and made with FR-4 material, High Layer PCBs are also suitable for use in consumer electronics, such as smartphones, tablets, and laptops. These boards can be customized to meet the specific requirements of each device, ensuring optimal performance and reliability.

In summary, the High Layer PCB product is ideal for applications where high performance, reliability, and density are essential. With a layer count of up to 40, multiple surface finish options, and a board thickness ranging from 0.2mm to 6.0mm, these PCBs are suitable for use across multiple industries, including automotive, aerospace, medical, telecommunications, and consumer electronics.

Customization:

Our High Layer PCB products can be customized to fit your specific needs. We offer the following customization services:

• Silkscreen Color: White, Black, Yellow
• Board Thickness: 0.2mm To 6.0mm
• Copper Thickness: 1/3 Oz To 2 Oz
• Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin
• Solder Mask Color: Green, Blue, Black, Red, Yellow, White

Our High Layer Multi-level PCB, also known as High Layer Printed Wiring Board, is designed for high density interconnect applications. With our customization services, we can create a PCB that meets your specific requirements.

Support and Services:

The High Layer PCB product offers technical support and services to ensure smooth and efficient operation. Our team of experts is available to provide assistance with:

• Design review and optimization
• Material selection
• Manufacturing process guidance
• Testing and quality control
• Customization and customization services

We are committed to providing our customers with high-quality products and a positive customer experience. Contact us for any technical support or service needs related to our High Layer PCB product.

Packing and Shipping:

Product Packaging:

The High Layer PCB product will be packaged in a sturdy cardboard box with foam inserts to ensure it arrives safely. Each PCB board will be individually wrapped in anti-static material to prevent any damage from static electricity.

Product Shipping:

We offer worldwide shipping for our High Layer PCB product. Our standard shipping method is through trusted courier services, with tracking information provided to the customer. If expedited shipping is required, please contact our customer service team to arrange for faster delivery.

FAQ:

A High Layer PCB (Printed Circuit Board) is a circuit board with more than 4 layers of conductive material. It is designed for applications that require a higher level of complexity and density.

The maximum number of layers that High Layer PCB can have is 30.

The advantages of a High Layer PCB include higher density, smaller size, better signal quality, and reduced electromagnetic interference (EMI).

The minimum order quantity for High Layer PCBs is 5 pieces.

The lead time for High Layer PCBs depends on the complexity and quantity of the order. Typically, it takes 7-10 days for a standard order.
