CEM-3 Aluminum Base Drone PCB Board White Silkscreen Circuit Board Assembly

Place of Origin Shenzhen, China
Brand Name Ben Qiang
Certification ISO/TS16949/RoHS/TS16949
Model Number FR-4/Rogers
Minimum Order Quantity 1PCS
Price custom made
Packaging Details Air bead vacuum packaging
Delivery Time 3-7 days delivery
Payment Terms Bank Transfer/Alipay/PayPal
Supply Ability 200,000 square meters/year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Board Thickness 1.6mm Solder Mask Color Green
Special Features Lightweight And Durable Design Min. Trace Width 0.1mm
Material FR-4 Base Material FR-4,CEM-3,Aluminum,CEM-1 OR FR-4,alum
Min. Trace Spacing 0.1mm Min. Hole Size 0.2mm
High Light

Drone PCB Board White Silkscreen

,

CEM-3 Drone PCB Board

,

Aluminum Base circuit board assembly

Leave a Message
Product Description

4 Layer Drone PCB Board Featuring White Silkscreen Color and 0.1mm Min. Trace Spacing



Product Description:

Drone PCB Board - Product Overview

Key Features
  • Surface Finish: HASL
  • Copper Thickness: 1oz
  • Min. Trace Width: 0.1mm
  • Min. Trace Spacing: 0.1mm
  • Product Type: PCB Board
  • Surface Finish: HASL
  • Copper Thickness: 1oz
  • Min. Trace Width: 0.1mm
  • Min. Trace Spacing: 0.1mm
  • Product Type: PCB Board
  • High Quality Material

Drone PCB Board is made with high quality material, ensuring durability and reliability. The material used is carefully selected to withstand harsh conditions and provide long-lasting performance in the operation of drones.

Stable Performance

Drone PCB Board offers stable performance, which is crucial for the smooth operation of drones. The board is designed to handle high frequencies and ensure accurate signal transmission, resulting in a stable and responsive drone flying experience.



Features:

Product Features:
  • Product Name: Drone PCB Board
  • Solder Mask Color: Green
  • Layer Count: 4
  • Min. Trace Spacing: 0.1mm
  • Pcb Assembly Method: Mixed, BGA, SMT, Through-hole
  • Min. Trace Width: 0.1mm
  • Unpiloted Flying Machine Board
  • UAV Electronic Board Module
  • Quadcopter Motherboard Assembly


Technical Parameters:

Product Name Drone PCB Board
Product Type Unmanned Aerial Vehicle PCB Board, Unpiloted Flying Machine Board, Quadcopter Motherboard Assembly
Board Thickness 1.6mm
Min. Hole Size 0.2mm
Material FR-4
Surface Finish HASL
Layer Count 4
Silkscreen Color White
Base Material FR-4, CEM-3, Aluminum, CEM-1 OR FR-4, Aluminum
Min. Trace Width 0.1mm
Min. Trace Spacing 0.1mm


Applications:

Aircraft PCB Circuit Board for Unmanned Aerial Vehicle



Application Areas

The Drone PCB Board is suitable for a wide range of industries and applications, making it an essential part of any UAV system. Some of the key areas where this product can be used include:

  • Military and Defense: The military sector is one of the biggest users of UAV technology, and the Drone PCB Board is an integral part of these drones. It is designed to withstand extreme conditions and ensure accurate and stable operation in surveillance, reconnaissance, and combat missions.
  • Agriculture: Drones equipped with the Drone PCB Board are used in agriculture for crop monitoring, spraying, and other tasks. The lightweight and durable design of the board makes it ideal for use in agricultural drones, allowing them to cover large areas and provide precise data for efficient farming.
  • Infrastructure Inspection: The Drone PCB Board is also used in infrastructure inspection, such as bridges, power lines, and pipelines. Its high-quality circuitry and advanced features make it a reliable tool for gathering data and detecting potential issues in critical structures.
  • Search and Rescue: In emergency situations, drones equipped with the Drone PCB Board can be used for search and rescue missions. Its compact design and advanced capabilities allow it to navigate through difficult terrain and provide real-time images and data to assist in rescue efforts.
Special Features

The Drone PCB Board stands out from other PCB boards in the market due to its special features, including:

  • Lightweight and Durable Design: The use of FR-4 material in the construction of the board makes it lightweight yet robust, allowing it to withstand the vibrations and shocks that come with flying a UAV.
  • Mixed, BGA, SMT, and Through-hole Assembly: The Drone PCB Board utilizes a mixed assembly method, combining BGA, SMT, and through-hole components. This results in a more compact and efficient design, with improved functionality and durability.
  • Green Solder Mask and White Silkscreen: The board's distinctive green solder mask and white silkscreen make it easily recognizable and aesthetically pleasing, while also providing clear markings for component placement and identification.

Overall, the Drone PCB Board is a highly versatile and reliable product that is essential for the smooth operation of any UAV. Its advanced features, durable design, and compatibility with various assembly methods make it a top choice for drone manufacturers and users alike.
