Radio Frequency RF Antenna PCB SMA Male Connector Radar Systems
Place of Origin | Shenzhen, China |
---|---|
Brand Name | Ben Qiang |
Certification | ISO/TS16949/RoHS/TS16949 |
Model Number | FR-4/Rogers |
Minimum Order Quantity | 1PCS |
Price | custom made-depond on gerber files |
Packaging Details | Air bead vacuum packaging |
Delivery Time | 3-7 days delivery |
Payment Terms | Bank Transfer/Alipay/PayPal |
Supply Ability | 200,000 square meters/year |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xPolarization | Linear | Input Power | 50W |
---|---|---|---|
Frequency Range | 2.4GHz - 2.5GHz | Impedance | Custom Made |
Connector Type | SMA Male | Material | FR4 |
Rohs Compliant | Yes | Vswr | ≤1.5 |
High Light | Radio Frequency RF Antenna PCB,RF Antenna PCB SMA Male Connector |
High-Performance RF Antenna PCB 50Ω Impedance Vswr≤1.5 Rohs Compliant
Product Description:
The RF Antenna PCB, also known as Receiving Antenna Circuit Board, Signal Antenna Circuit Board, or Radio Frequency Antenna Printed Circuit Board, is an essential component in wireless communication systems. It is designed to receive and transmit radio frequency signals, making it a crucial part of any wireless communication device.
Operating Temperature: The RF Antenna PCB is able to operate efficiently in a wide temperature range, from -40°C to +85°C. This makes it suitable for use in extreme weather conditions and ensures its reliability and performance in various environments.
Gain: With a gain of 2dBi, the RF Antenna PCB is able to amplify the signal it receives, making it an ideal choice for wireless communication devices. This ensures a strong and stable signal transmission, improving the overall performance of the device.
VSWR: The RF Antenna PCB has a VSWR (Voltage Standing Wave Ratio) of ≤1.5, which means it has a low level of reflected power. This ensures maximum power transfer between the antenna and the device, resulting in better signal quality.
Application: The RF Antenna PCB is primarily used in wireless communication systems, such as mobile phones, routers, and other electronic devices. It plays a crucial role in enabling these devices to send and receive data wirelessly, making it an essential component in modern communication technology.
Impedance: The RF Antenna PCB has an impedance of 50Ω, which is the ideal impedance for efficient signal transmission. This ensures that the antenna is perfectly matched with the device, preventing signal loss and interference.
Features:
- Product Name: RF Antenna PCB
- Material: FR4
- Vswr: ≤1.5
- Radiation Pattern: Omni-directional
- Frequency Range: 2.4GHz - 2.5GHz
- Gain: 2dBi
- Key Features:
- Designed for RF Antenna PCB
- Made with high-quality FR4 material
- Low Vswr for optimal signal performance
- Omni-directional radiation pattern for 360° coverage
- Compatible with frequency range of 2.4GHz - 2.5GHz
- Provides 2dBi gain for enhanced signal strength
- Ideal for Signal Antenna Circuit Board and Receiving Antenna Circuit Board
Technical Parameters:
Radio Antenna Circuit Board | Radio Frequency Antenna Printed Circuit Board |
---|---|
Material | FR4 |
Rohs Compliant | Yes |
Dimensions | 50mm X 50mm X 1.6mm |
Connector Type | SMA Male |
Operating Temperature | -40°C To +85°C |
Mounting Type | Surface Mount |
Vswr | ≤1.5 |
Impedance | 50Ω |
Polarization | Linear |
Application | Wireless Communication |
Radio Frequency Antenna Printed Circuit Board Technical Specifications | |
---|---|
Material | FR4 |
Rohs Compliant | Yes |
Dimensions | 50mm X 50mm X 1.6mm |
Connector Type | SMA Male |
Operating Temperature | -40°C To +85°C |
Mounting Type | Surface Mount |
Vswr | ≤1.5 |
Impedance | 50Ω |
Polarization | Linear |
Application | Wireless Communication |
Applications:
The RF Antenna PCB (Radio Frequency Antenna Printed Circuit Board) is a signal antenna circuit board designed for receiving and transmitting radio frequency signals. It is a vital component in various electronic devices such as mobile phones, routers, and wireless communication systems. With its high-quality design and advanced technology, the RF Antenna PCB is widely used in different applications to improve wireless communication.
Impedance | 50Ω |
---|---|
Mounting Type | Surface Mount |
Radiation Pattern | Omni-directional |
Connector Type | SMA Male |
Polarization | Linear |
The RF Antenna PCB is designed with the following key attributes to ensure its superior performance:
- Impedance: With an impedance of 50Ω, the RF Antenna PCB is able to match the impedance of most electronic devices, allowing for efficient transmission and reception of signals.
- Mounting Type: The surface mount design of the RF Antenna PCB makes it easy to install on the surface of a circuit board, saving space and reducing production costs.
- Radiation Pattern: The omni-directional radiation pattern of the RF Antenna PCB allows for 360-degree coverage, ensuring a strong and stable signal transmission in all directions.
- Connector Type: The SMA male connector on the RF Antenna PCB provides a secure and reliable connection, making it compatible with a wide range of devices.
- Polarization: The linear polarization of the RF Antenna PCB ensures that the electric field of the transmitted signal remains in a fixed direction, minimizing interference and improving signal quality.
The RF Antenna PCB has a wide range of applications in various industries, including:
- Wireless Communication: The RF Antenna PCB is used in mobile phones, routers, and other wireless communication devices to transmit and receive signals for voice, data, and internet connectivity.
- Satellite Communication: The RF Antenna PCB is used in satellite communication systems to send and receive data and signals from satellites orbiting the Earth.
- Internet of Things (IoT): The RF Antenna PCB is used in IoT devices to enable wireless communication and connectivity, allowing for remote control and data transfer between devices.
- Radar Systems: The RF Antenna PCB is used in radar systems for military and civilian applications, such as air traffic control, weather monitoring, and defense systems.
- Medical Devices: The RF Antenna PCB is used in medical devices for wireless communication between sensors, monitors, and other medical equipment, enabling remote patient monitoring and data collection.
With its versatile applications and advanced technology, the RF Antenna PCB plays a crucial role in enhancing wireless communication in various industries. Its superior performance and reliable design make it a top choice for engineers and manufacturers looking to improve the efficiency and reliability of their electronic devices.
Customization:
Our RF Antenna PCB is a highly customizable product designed for wireless communication applications. With a gain of 2dBi and an omni-directional radiation pattern, this antenna is perfect for both receiving and transmitting signals.
Our RF Antenna PCB is specifically designed for wireless communication applications, making it ideal for use in various industries such as telecommunications, consumer electronics, and automotive.
The antenna has a gain of 2dBi, providing a strong and stable signal reception for your wireless communication needs.
The omni-directional radiation pattern of our RF Antenna PCB ensures that the antenna can receive and transmit signals in all directions, making it perfect for applications where a wide coverage is required.
Our RF Antenna PCB is designed for surface mount installation, making it easy to integrate into your existing wireless communication systems.
The antenna has a VSWR of ≤1.5, ensuring minimal signal loss and maximum efficiency in your wireless communication system.
At our company, we understand that every application is unique and requires a tailored solution. That's why we offer a highly customizable service for our RF Antenna PCB. From the shape and size of the antenna to the materials used, we can work with you to create a product that meets your specific needs and requirements.
Packing and Shipping:
The RF Antenna PCB is carefully packaged to ensure its safe delivery to customers. The packaging process includes the following steps:
- Step 1: The RF Antenna PCB is placed in a protective plastic bag to prevent any scratches or damage during shipping.
- Step 2: The plastic bag is then placed in a sturdy cardboard box to provide further protection.
- Step 3: The box is sealed with packing tape to prevent any accidental opening during transit.
- Step 4: The box is labeled with the product name, model number, and shipping address.
- Step 5: The box is then placed in a larger shipping box with additional cushioning materials for added protection.
Once the RF Antenna PCB is properly packaged, it is ready for shipping. We offer various shipping options based on customer preferences and location. Our shipping partners ensure timely and safe delivery of the product to its destination. Customers can track their order using the provided tracking number.
For international orders, we take extra precautions to comply with customs regulations and ensure smooth delivery. Our team carefully packs the product to meet the specific requirements of each destination country.
At RF Antenna, we take pride in our packaging and shipping process to ensure that our customers receive their products in excellent condition.
FAQ:
- Q: What is the RF Antenna PCB's frequency range?
- A: The RF Antenna PCB has a frequency range of 2.4GHz to 5GHz.
- Q: What is the size of the RF Antenna PCB?
- A: The RF Antenna PCB has a size of 10mm x 10mm.
- Q: Does the RF Antenna PCB support multiple protocols?
- A: Yes, the RF Antenna PCB supports multiple protocols such as Wi-Fi, Bluetooth, and Zigbee.
- Q: What is the maximum power handling capacity of the RF Antenna PCB?
- A: The RF Antenna PCB can handle a maximum power of 20dBm.
- Q: Is the RF Antenna PCB suitable for outdoor use?
- A: No, the RF Antenna PCB is designed for indoor use only.
