2dBi Gain Rfid PCB Antenna For High Speed Wireless Communication

Place of Origin Shenzhen, China
Brand Name Ben Qiang
Certification ISO/TS16949/RoHS/TS16949
Model Number FR-4/Rogers
Minimum Order Quantity 1PCS
Price custom made
Packaging Details Air bead vacuum packaging
Delivery Time 3-7 days delivery
Payment Terms Bank Transfer/Alipay/PayPal
Supply Ability 200,000 square meters/year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector Type SMA Male Polarization Linear
Dimensions 50mm X 50mm X 1.6mm Gain 2dBi
Vswr ≤1.5 Operating Temperature -40°C To +85°C
Frequency Range 2.4GHz - 2.5GHz Impedance 50Ω
