0.3mm Minimum Hole Size Thick Power PCB with Copper and Impedance Control

Product Description:

Features:

• Product Name: Thick copper power PCB
• Minimum Hole Size: 0.3mm
• Minimum Trace Width: 0.2mm
• Surface Finish: ENIG
• Silkscreen Color: White
• Thickness: 3.2mm
• Thick copper power PCB
• PCB with power thick copper
• Copper power PCB with thick traces

Technical Parameters:

Applications:

The Thick Copper Power PCB is a type of printed circuit board that is specifically designed to handle high power and heavy current applications. It is characterized by its thick copper layers and sturdy construction, making it an ideal choice for demanding and rugged environments.

With a thickness of 1.6mm and a copper thickness of 3oz, this PCB is able to handle high currents and provide efficient power distribution. It is also available in a 14-layer design, making it a cost-effective option for various applications.

The Thick Copper Power PCB is compliant with the Restriction of Hazardous Substances (RoHS) directive, ensuring that it is safe for both the environment and human health. It is also equipped with a ENIG surface finish, which provides a flat and uniform surface for better solderability and reliability.

The Thick Copper Power PCB is suitable for a wide range of applications, especially those that require high power and heavy current handling. Some of its common applications include:

• Power Supplies: The Thick Copper Power PCB is commonly used in power supply units for various electronic devices, including computers, telecommunication equipment, and industrial machinery.
• Motor Control: With its ability to handle high currents, this PCB is an ideal choice for motor control applications, such as in electric vehicles, elevators, and industrial robots.
• Power Inverters: The Thick Copper Power PCB is also widely used in power inverters for solar panels, wind turbines, and other renewable energy systems.
• Heavy Machinery: Due to its sturdy construction and high power handling capabilities, this PCB is commonly used in heavy machinery, such as construction equipment, mining equipment, and agricultural machinery.

The Thick Copper Power PCB offers several key features that make it stand out from other types of PCBs. These include:

• Thick Copper Layers: With a copper thickness of 3oz, this PCB is able to handle high currents without overheating or causing voltage drops.
• Sturdy Construction: The Thick Copper Power PCB is designed to withstand harsh environments and heavy-duty applications, making it highly durable and reliable.
• Cost-Effective: Despite its heavy copper layers, this PCB is available in a 14-layer design, making it a cost-effective option for high power applications.
• RoHS Compliant: This PCB is compliant with the RoHS directive, ensuring that it is free from hazardous substances and safe for the environment and human health.
• ENIGSurface Finish: The ENIG surface finish provides a flat and uniform surface for better solderability and reliability, ensuring a strong and stable connection between components.

Overall, the Thick Copper Power PCB is a reliable and efficient solution for high power and heavy current applications. Its thick copper layers and sturdy construction make it a top choice for demanding environments, while its cost-effectiveness and compliance with safety standards make it a preferred option for a wide range of industries.

Customization:

Our Thick Copper Power PCB is designed to meet your specific needs and requirements. With our top-of-the-line customization service, we guarantee that your power PCB will deliver exceptional performance and reliability.

• Impedance Control: Yes
• Silkscreen Color: White
• Maximum Panel Size: 600mm X 600mm
• Solder Mask Color: Green
• Copper Thickness: 3oz

Our Thick Copper Power PCB is the perfect solution for high-power applications that require efficient heat dissipation and reliable performance. With our customization service, you can rest assured that your power PCB will have the following attributes:

• Thick copper for improved heat dissipation
• High-quality copper material for enhanced conductivity
• Customized impedance control for optimal signal transmission
• White silkscreen for clear and precise labeling
• Maximum panel size of 600mm X 600mm for larger and more complex designs
• Green solder mask for protection against environmental factors

At our company, we understand the importance of a reliable and high-performance power PCB for your business. That's why we offer a comprehensive customization service to ensure that your Thick Copper Power PCB meets your exact specifications and requirements. Trust us to deliver a top-quality Copper Thick Power PCB that will exceed your expectations.

Packing and Shipping:

Thick copper power PCB is carefully packaged and shipped to ensure safe delivery to our customers. The packaging process involves the following steps:

• Each PCB is placed in an anti-static bag to protect it from static electricity during transportation.
• The PCB is then placed in a foam-lined box to provide cushioning and prevent damage during shipping.
• The box is sealed and labeled with the product name, quantity, and other relevant information.

Our standard shipping method is through reputable courier services, such as DHL, UPS, and FedEx. We also offer air freight and sea freight options for larger orders.

All shipments are insured to protect against any damage or loss during transit. Customers can track their shipment using the provided tracking number.

We strive to ensure that our packaging and shipping process meets the highest standards to guarantee the safe arrival of our products to our customers.

FAQ:

• Q1:What is the thickness of the copper layer on Thick copper power PCB?
• A1:The thickness of the copper layer on Thick copper power PCB is usually ≥2oz (70 μm).

• Q2:What is the maximum operating temperature for Thick copper power PCB?
• A2:The maximum operating temperature for Thick copper power PCB is usually 130-150°C, but it can be customized to meet specific requirements.

• Q3:What is the difference between Thick copper power PCB and standard PCB?
• A3:Thick copper power PCB has a thicker copper layer, usually ≥2oz (70 μm), which allows it to handle higher current and heat dissipation compared to standard PCB.

• Q4:Can Thick copper power PCB be used for high-power applications?
• A4:Yes, Thick copper power PCB is specifically designed for high-power applications, such as power supplies, motor controllers, and inverters.

• Q5:Is Thick copper power PCB suitable for surface mount technology (SMT) assembly?
• A5:Yes, Thick copper power PCB can be designed for SMT assembly, but it is recommended to consult with the manufacturer to ensure proper compatibility and optimization of the design.
